Self Propelled Scissor Lift

Overview:

Our self propelled scissor lift series is designed for both indoor and outdoor aerial work, offering stable lifting from 3m to 16m. Equipped with electric drive and hydraulic lift systems, these electric scissor lifts feature proportional control, automatic braking, and comprehensive safety protection systems for reliable and efficient operation.

Features:

• Proportional control for precise operation.

• Automatic braking system ensures safety during stopping and parking.

• Extendable platform for larger working areas.

• Automatic pothole protection system for enhanced ground stability.

• Emergency lowering system and emergency stop button for unexpected power loss.

• Horn and flashing light for operation warning.

• Battery protection & charging system for longer service life.

• Self-locking gate & safety inspection support bar.

• Full-travel drive function allows movement even when elevated.

• Tilt protection system and anti-collision bars.

• Non-marking solid tires for indoor clean environments.

• Hydraulic hose burst protection system and fault diagnostic system.

• Standard forklift holes for easy loading and transport.

Specification:

Model	Max. Lifting Height (m)	Work Load (kg)	Platform Size(mm)	Outline Dimension Guardrail Unfolded (mm)	Extended Platform (mm)	Dead Weight(kg)
KNSL-4	4	240	1290*700	1425*760*2005	600	980
KNSL-6 Mini	5.8	230	1670*740	1855*790*2210	900	1620
KNSL-6A	6	380	2260*810	2490*840*2200	900	1880
KNSL-6	6	550	2260*1150	2490*1190*2200	900	2150
KNSL-8A	8	230	2260*810	2490*840*2320	900	2050
KNSL-8	8	450	2260*1130	2490*1190*2320	900	2300
KNSL-10	10	320	2300*1120	2490*1190*2460	900	2540
KNSL-12	11.8	320	2300*1120	2490*1190*2580	900	2880
KNSL-14	13.8	227	2640*1125	2840*1395*2592	900	3410

Advantages:

• Compact structure and strong lifting performance.

• Low noise, long battery life, suitable for indoor/outdoor work.

• Efficient hydraulic system with reliable oil control valves.

• Smart diagnostic system simplifies maintenance.

• High-strength steel structure ensures long lifespan.

Application:

Ideal for warehouse maintenance, installation work, indoor/outdoor construction, and equipment repair where stable, mobile, and quiet aerial lifting is required.

Need a customized self propelled scissor lift or hydraulic scissor lift table? Contact us now or send your requirements for lifting height, load, and working environment.
